Zamboni - 445 Zamboni Ice Resurfacer

The 446 Ice Resurfacer

The 446 is simple to drive and very easy to operate.

The ergonomically designed, roomy and comfortable operator’s compartment has easy-to-read gauges and instructions and comes with a modern steering wheel and spinner knob. All the operator has to do is set the engine speed with the hands-free governor and drive the machine using a familiar automobile-style foot control.

Speed is controlled by this single foot pedal that is equipped with a feature that will stop the machine if the operator's foot leaves the pedal. The smaller, more efficient engine provides fuel savings and a cleaner arena environment.

The 446 has it all… maneuverability, performance and dependability.

controlseat

The Ultimate Machine

Our engine and hydrostatic transmission enable the 446 to use a smaller, more efficient engine and can provide significant fuel savings.

Zamboni ice resurfacers have a well-deserved reputation for producing the finest sheet of ice using our unique down pressure system.

  • Serviceability

    Wide-open access epitomizes Zamboni's commitment to providing the highest level of serviceability. Daily checks of fluid levels and other maintenance items can easily be performed. With it's CAN bus system and multi-function display, manufacturer's recommended oil change and tune-up intervals are programmed into the machine and are accessible for review on the dash display. The operator can plan ahead with the visible countdown leading up to service intervals.

  • Transmission

    Continuously variable hydrostatic pump and motor are axial-piston type. Provides superior on-ice power with maximum drawbar pull even at low speeds. Full hydro-dynamic braking.

  • Hydraulics

    Powerful single pump for the vertical and horizontal augers delivers strong conveyor performance. Hydraulic down pressure provides superior shaving results. Direct shaft driven "piggy-back" mount for trouble-free service. High quality 10 and 25 micron filters are easy to access.

  • Drivetrain

    Four wheel drive. Rugged Dana Spicer® axles offer the industry's highest manufacturers approved capacities. Front 4300 lbs. (1950 kg) Rear 4800 lbs. (2177 kg) Semi Floating

  • Construction

    Strong 3" x 5" all-welded steel tubing Zamboni chassis. Chassis/axle combination is the key to the 446 having a 15' turning radius - a full 3' tighter than most other machines. High quality primer used throughout. Rust-free polyethylene ice making water tank with easy access cover is standard.
